Product parameters
Model : JTK-508Type : Stamp printing machinePrinting direction: one-way printingApplicable workpiece: planePacking type: boxDegree of automation: manual Steel plate: The alloy steel rotary plate heat-treated by high-frequency quenching is printed with a certain depth (0.1∽0.3mm deep) letters or numbers on the metal sign under the action of external force (by hand or rubber hammer); The steel dial can be rotated to the desired letter or digital automatic card position, and the word conversion can be easily realized; the marking position and the line spacing can be manually adjusted by the mechanical mechanism; different word heights can be realized by replacing the dial; the shape length is less than 185mm and the height is less than 2mm. Shape signs can be stamped and engraved.CharacteristicsThe utility model has the advantages of small volume, light weight, convenient and convenient operation, neat printing and writing, uniform and clear lines, and various font sizes.Steel plate material:winding steel 12 Hardness: 58-60HV Straight: 84mm Inner hole: 14mmNo.2:height 2 mm width 1.2 mm tooth width 4 mm thickness 6 mmNo.2.5:Height 2.5 mm Wide 1.4 mm Tooth width 4 mm Thickness 6 mmNo.3: Height 3 mm width 1.6 mm Tooth width 4 mm Thickness 6 mmNo.4: Height 4 mm Width 2.1 mm Tooth width 4.5 mm Thickness 6 mmNo.5: Height 5 mm Width 2.6 mm Tooth width 4.5 mm Thickness 6 mmNote: small letters in the number (1) small characters in the symbol (.) in English small characters (I) large characters (MW)The word wheel number contains:Capital letters: ABCDEFGHIJKLMNOPQRSTUVWXYZArabic numerals: 1234567890
Products real shot
